概述
GD32H759产品系列支持CAN-FD。其主频高达600MHz ，支持高达3840K Flash和1024K SARM；辜闪薝SB OTG、TFT-LCD、SAI、以太网以及其他数字和模拟表设资源。
GD32H759 产品系列提供 LQFP176 和 BGA176 封装选项。
产品选择器
6条了局
|
Part No.
|
Core
|
Series
|
Package
LQFP176
BGA176
|
Max Speed (MHz)
|
Flash (Bytes)
1024K
2048K
3840K
|
SRAM (Bytes)
|
I/O
up to 134
up to 121
|
GPTM (32bit)
|
GPTM (16bit)
|
Advanced TM (16bit)
|
HRTM
|
Basic TM (64bit)
|
CPTM (16bit)
|
Basic TM (32bit)
|
Basic TM (16bit)
|
LPTM (32bit)
|
LPTM (16bit)
|
SysTick (64bit)
|
SysTick (24bit)
|
WDG
|
RTC
|
USART+UART
|
LPUART
|
I2C
|
QSPI
|
SPI
|
I2S
|
CAN 2.0B
|
USB 2.0
|
Ethernet
|
SDIO
|
EtherCAT Slave Controller
|
MFCOM
|
LIN
|
LCD-TFT
|
MIPI-DSI
|
Segment LCD
|
Camera
|
IPA
|
SAI
|
TMU
|
EXMC
|
CEC
|
14bit ADC Units (CHs)
1(20), 1(18)
1(16), 1(14)
|
12bit ADC Units (CHs)
1(17)
1(12)
|
12bit DAC Units
|
Comp
|
IEEE 802.11
|
Bluetooth
|
Dflash(Bytes)
|
SENT
|
Functional Safety
|
Security
|
Temperature Range(TA)
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Cortex?-M7 | GD32H759 | LQFP176 | 600 | 1024K | 1024K | up to 121 | 4 | 12 | 2 | 0 | 2 | 0 | 2 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 8 | 0 | 4 | 2 | 6 | 4 | 3xFD | 2x(FS+HS) OTG | 1 | 2 | 0 | 0 | 0 | 1 | 0 | 0 | 0 | 1 | 3 | 1 | 1 | 0 | 1(16), 1(14) | 1(12) | 1 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | -40℃~85℃ | |
| Cortex?-M7 | GD32H759 | LQFP176 | 600 | 2048K | 1024K | up to 121 | 4 | 12 | 2 | 0 | 2 | 0 | 2 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 8 | 0 | 4 | 2 | 6 | 4 | 3xFD | 2x(FS+HS) OTG | 1 | 2 | 0 | 0 | 0 | 1 | 0 | 0 | 0 | 1 | 3 | 1 | 1 | 0 | 1(16), 1(14) | 1(12) | 1 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | -40℃~85℃ | |
| Cortex?-M7 | GD32H759 | LQFP176 | 600 | 3840K | 1024K | up to 121 | 4 | 12 | 2 | 0 | 2 | 0 | 2 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 8 | 0 | 4 | 2 | 6 | 4 | 3xFD | 2x(FS+HS) OTG | 1 | 2 | 0 | 0 | 0 | 1 | 0 | 0 | 0 | 1 | 3 | 1 | 1 | 0 | 1(16), 1(14) | 1(12) | 1 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | -40℃~85℃ | |
| Cortex?-M7 | GD32H759 | BGA176 | 600 | 1024K | 1024K | up to 134 | 4 | 12 | 2 | 0 | 2 | 0 | 2 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 8 | 0 | 4 | 2 | 6 | 4 | 3xFD | 2x(FS+HS) OTG | 2 | 2 | 0 | 0 | 0 | 1 | 0 | 0 | 0 | 1 | 3 | 1 | 1 | 0 | 1(20), 1(18) | 1(17) | 1 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | -40℃~85℃ | |
| Cortex?-M7 | GD32H759 | BGA176 | 600 | 2048K | 1024K | up to 134 | 4 | 12 | 2 | 0 | 2 | 0 | 2 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 8 | 0 | 4 | 2 | 6 | 4 | 3xFD | 2x(FS+HS) OTG | 2 | 2 | 0 | 0 | 0 | 1 | 0 | 0 | 0 | 1 | 3 | 1 | 1 | 0 | 1(20), 1(18) | 1(17) | 1 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | -40℃~85℃ | |
| Cortex?-M7 | GD32H759 | BGA176 | 600 | 3840K | 1024K | up to 134 | 4 | 12 | 2 | 0 | 2 | 0 | 2 | 0 | 0 | 0 | 0 | 1 | 2 | 1 | 8 | 0 | 4 | 2 | 6 | 4 | 3xFD | 2x(FS+HS) OTG | 2 | 2 | 0 | 0 | 0 | 1 | 0 | 0 | 0 | 1 | 3 | 1 | 1 | 0 | 1(20), 1(18) | 1(17) | 1 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | -40℃~85℃ |
